SANUS Preferred 42"-100" Advanced Tilt TV Wall Mount, 6" Extend Medium SLT4B-B1

$99.99
Unit price per
Save $80

Shipping calculated at checkout.

SANUS Preferred SLT4B-B1 Advanced Tilt TV Wall Mount for 42"–100" TVs up to 150 lbs, +7°/-12° Tilt & 6" Extension

The SANUS Preferred SLT4B-B1 Advanced Tilt TV Wall Mount is designed for large TVs from 42 to 100 inches and supports displays weighing up to 150 lbs. Its low-profile design keeps the TV approximately 2.96 inches from the wall while allowing nearly 6 inches of extension for easier viewing adjustments and cable access.

Finger-touch tilt provides +7° upward and -12° downward adjustment, while up to 8 inches of lateral shift helps position the TV after installation. Compatible with VESA patterns from 200 x 100 through 900 x 600, the mount can be installed on wood studs, concrete, or concrete block walls and includes mounting hardware for a streamlined DIY installation.

Key Features

Fits most 42" to 100" TVs
Supports TVs weighing up to 150 lbs.
Advanced tilting TV wall mount design
Low-profile installation sits approximately 2.96" from the wall
Extends up to 5.96" from the wall
Finger-touch tilt adjustment
Tilts up to +7° upward
Tilts up to -12° downward
Up to 8" lateral shift for side-to-side TV positioning
1" height adjustment for installation fine-tuning
Up to 6° post-install leveling adjustment
Compatible with VESA patterns from 200 x 100 to 900 x 600
Compatible with wood stud walls
Compatible with concrete and concrete block walls
Tilting design provides easier access to cables behind the TV
Locking mechanism for secure installation
Safety tab provides an audible connection indication
Mounting hardware included
UL Listed
Black finish
10-year warranty

Specifications

Brand: SANUS
Product Name: SANUS Preferred Advanced Tilt TV Mount
Model: SLT4B-B1
Mount Type: Tilt
Color: Black
Minimum TV Size: 42 in.
Maximum TV Size: 100 in.
Weight Capacity: 150 lb.
Minimum VESA Pattern: 200 x 100
Maximum VESA Pattern: 900 x 600
Minimum Depth from Wall: 2.96 in.
Maximum Extension: 5.96 in.
Tilt Range: +7° / -12°
Lateral Shift Range: Up to 8 in.
Height Adjustment: 1 in.
Post-Installation Leveling: Up to 6°
Mount Dimensions: 37.5 in. W x 24.9 in. H
Compatible Wall Types: Wood Stud, Concrete, Concrete Block
Mount Features: UL Listed, Locking Mechanism, Mounting Hardware Included
Warranty: 10 Years

What's Included

1 SANUS SLT4B-B1 Advanced Tilt TV Wall Mount
Mounting Hardware
Installation Instructions

Ideal For

42" to 100" flat-screen TVs
Large-screen televisions
TVs weighing up to 150 lbs.
Living rooms
Home theaters
Bedrooms
Entertainment rooms
Offices and conference rooms
Wood stud wall installations
Concrete and concrete block wall installations
Installations requiring tilt adjustment
Installations requiring side-to-side positioning after mounting
Users who need easier access to cables behind the TV

Why It Stands Out

The SANUS SLT4B-B1 offers more adjustment flexibility than a basic fixed or conventional tilting TV mount. While maintaining a clean, low-profile appearance at approximately 2.96 inches from the wall, the mount can extend nearly 6 inches outward, providing additional space for cable access and installation adjustments.

The +7°/-12° finger-touch tilt range helps optimize viewing from different seating positions and can reduce unwanted screen reflections. An 8-inch lateral shift range allows the mounted TV to move side to side, making it easier to center the screen even when wall studs are not positioned exactly where you want the TV.

Additional fine-tuning is available through 1-inch height adjustment and up to 6° post-install leveling, helping correct positioning after the mount is already secured to the wall.

With support for TVs up to 100 inches and 150 lbs., a broad 200 x 100 to 900 x 600 VESA range, UL listing, included mounting hardware, and compatibility with multiple wall types, the SLT4B-B1 is designed for secure and flexible large-screen TV installations.

Frequently Asked Questions

What TV sizes fit the SANUS SLT4B-B1?

The mount is designed for compatible TVs ranging from 42 inches to 100 inches.

What is the maximum TV weight supported?

The maximum listed weight capacity is 150 pounds.

What VESA patterns are compatible?

The mount supports VESA mounting patterns ranging from 200 x 100 to 900 x 600. Your TV's VESA pattern and weight should both fall within the mount's specifications.

How far does the TV sit from the wall?

At its minimum position, the mount places the TV approximately 2.96 inches from the wall.

Can the TV extend away from the wall?

Yes. The mount can extend up to approximately 5.96 inches, providing additional room for adjustments and easier cable access.

How much can the TV tilt?

The mount provides approximately +7° upward tilt and -12° downward tilt with finger-touch adjustment.

Can I move the TV sideways after installation?

Yes. The mount provides up to 8 inches of lateral shift, allowing side-to-side positioning to help center the TV on the wall.

Can the TV be leveled after the mount is installed?

Yes. The mount provides up to 6 degrees of post-install leveling adjustment, along with approximately 1 inch of height adjustment for additional fine-tuning.

What types of walls can this mount be installed on?

The mount is compatible with wood stud, concrete, and concrete block walls when installed according to the manufacturer's instructions using the appropriate hardware and installation method.

Is mounting hardware included?

Yes. Mounting hardware is included.
